| Cutting Diameter (DC) | 9 mm | Body Material | Steel |
| Connection Diameter Machine Side (DCONMS) | 0.63″ | Tool Type | Indexable Reaming Tools |
| Application | | Reaming | | Measurement Type | Inch |
| Usable Length (LU) | 75 mm | Length Group | 2xD |
| Insert Seat Size Code (SSC) | T6 | Cutting Diameter Minimum (DCN) | 0.5314″ |
| Depth of Cut Maximum (APMX) | 15.5 mm | Cutting Diameter Maximum (DCX) | 0.6299″ |
| Overall Length (OAL) | 123.5 mm | Functional Length (LF) | 3.209″ |
| Shank Length (LS) | 45 mm | Head Length (LH) | 1.319″ |
Product Features
| Family Description | Indexable reamers for holemaking | Country of Origin | ISRAEL |
| Remarks | Maximum effective reaming depth = Head diameter (mm) x L/D ratio (ULDR). Ex. For a reamer with DC 12 mm: 12 mm × 3 = 36 mm |
